Home Thread tap VÖLKEL Hand Tap Finisher DIN 352 HSSE, M3 – M30
Categories
VÖLKEL Hand Tap Finisher DIN 352 HSSE, M3 – M30
Thread tap

VÖLKEL Hand Tap Finisher DIN 352 HSSE, M3 – M30

★ 0.0 (0 reviews)
Sold: 0
Views: 0
Imported from: Germany
Origin: Made in Germany

VÖLKEL Hand Tap Finisher DIN 352 HSSE, M3 – M30, 15 sizes. Dimensions per item in the size table.

SKU: ---
15 variants
€7.05 - €122.44
Stock status: Varies by SKU
Indicative price
Description

VÖLKEL Hand Tap Finisher DIN 352 HSSE, M3 – M30, 15 sizes. Dimensions per item in the size table.

Specifications

  • Hand tap, finisher (third tap) of hand tap set
  • Standard: DIN 352
  • Material: HSS-E (cobalt-alloyed high speed steel)
  • Thread system: metric ISO coarse thread
  • Thread tolerance class: ISO2 (6H)
  • Short chamfer lead for threading close to hole bottom
  • Square drive shank for tap wrench operation
  • Suitable for through holes and blind holes
  • Manual tapping with hand tap wrench
  • Function: cutting internal threads to full depth
  • Applications: maintenance, repair, toolmaking, jig and fixture work
  • Requires pilot hole drilling and edge chamfering before tapping
  • Cutting oil recommended, matched to workpiece material
  • Supply unit: one piece per size
  • Size: see variant table
  • Weight: see variant table
Price list & Ordering
Drag to reorder
SKU Code Price (EUR) Buy Stock Application Blade length DIN or ISO standard Drill hole diameter Material Overall length Shank diameter Square shank Thread size Thread tolerance class Thread type
57326-3 €7.05 Through and blind hole 11mm DIN 352 2,5 mm HSSE 40mm 3.5mm 2.7mm M 3 x 0.5 ISO2 (6H) Metric thread, right hand
57330-3 €7.18 Through and blind hole 13mm DIN 352 3,3 mm HSSE 45mm 4.5mm 3.4mm M 4 x 0.7 ISO2 (6H) Metric thread, right hand
57334-3 €7.55 Through and blind hole 16mm DIN 352 4,2 mm HSSE 50mm 6mm 4.9mm M 5 x 0.8 ISO2 (6H) Metric thread, right hand
57338-3 €7.55 Through and blind hole 19mm DIN 352 5 mm HSSE 50mm 6mm 4.9mm M 6 x 1.0 ISO2 (6H) Metric thread, right hand
57342-3 €10.24 Through and blind hole 22mm DIN 352 6,8 mm HSSE 56mm 6mm 4.9mm M 8 x 1.25 ISO2 (6H) Metric thread, right hand
57346-3 €13.49 Through and blind hole 24mm DIN 352 8,5 mm HSSE 70mm 7mm 5.5mm M 10 x 1.5 ISO2 (6H) Metric thread, right hand
57350-3 €16.68 Through and blind hole 29mm DIN 352 10,2 mm HSSE 75mm 9mm 7mm M 12 x 1.75 ISO2 (6H) Metric thread, right hand
57354-3 €19.00 Through and blind hole 30mm DIN 352 12 mm HSSE 80mm 11mm 9mm M 14 x 2.0 ISO2 (6H) Metric thread, right hand
57358-3 €24.64 Through and blind hole 32mm DIN 352 14 mm HSSE 80mm 12mm 9mm M 16 x 2.0 ISO2 (6H) Metric thread, right hand
57362-3 €34.94 Through and blind hole 40mm DIN 352 15,5 mm HSSE 95mm 14mm 11mm M 18 x 2.5 ISO2 (6H) Metric thread, right hand
57366-3 €39.24 Through and blind hole 40mm DIN 352 17,5 mm HSSE 95mm 16mm 12mm M 20 x 2.5 ISO2 (6H) Metric thread, right hand
57370-3 €47.43 Through and blind hole 40mm DIN 352 19,5 mm HSSE 100mm 18mm 14.5mm M 22 x 2.5 ISO2 (6H) Metric thread, right hand
57374-3 €65.18 Through and blind hole 50mm DIN 352 21 mm HSSE 110mm 18mm 14.5mm M 24 x 3.0 ISO2 (6H) Metric thread, right hand
57376-3 €113.31 Through and blind hole 50mm DIN 352 24 mm HSSE 110mm 20mm 16mm M 27 x 3.0 ISO2 (6H) Metric thread, right hand
57378-3 €122.44 Through and blind hole 56mm DIN 352 26,5 mm HSSE 125mm 22mm 18mm M 30 x 3.5 ISO2 (6H) Metric thread, right hand
