Home Thread plug gauge VÖLKEL GO thread plug gauge, UNC 1.5/8 – 3", tolerance 2B
Categories
VÖLKEL GO thread plug gauge, UNC 1.5/8 – 3", tolerance 2B
Thread plug gauge

VÖLKEL GO thread plug gauge, UNC 1.5/8 – 3", tolerance 2B

★ 0.0 (0 reviews)
Sold: 0
Views: 0
Imported from: Germany
Origin: Made in Germany

VÖLKEL GO thread plug gauge, UNC 1.5/8 – 3", 8 sizes, to ANSI B1.2. Separate GO gauge for large sizes. For internal threads after tapping or repair.

SKU: 1673x
8 variants
€214.29 - €433.22
Stock status: Varies by SKU
Indicative price
Description

VÖLKEL GO thread plug gauge, UNC 1.5/8 – 3", 8 sizes, to ANSI B1.2. Separate GO gauge for large sizes. For internal threads after tapping or repair.

Specifications

  • Function: GO limit gauge for internal threads
  • Checks threaded holes after tapping or thread repair
  • Single GO gauge supplied separately for large sizes
  • Pairs with matching NOGO gauge of same size
  • Right-hand thread
  • Unified Coarse inch thread system
  • Manufactured to ANSI B1.2
  • GO member must engage by hand without force
  • Inspection use only: not for cutting or reworking threads
  • Not suitable for external threads; use ring gauges
  • Applications: production, maintenance, tool rooms, incoming inspection
  • Supplied as one piece per size
Price list & Ordering
Drag to reorder
SKU Code Price (EUR) Buy Stock DIN or ISO standard Probe type Thread size Thread tolerance class Thread type
16733 €214.29 ANSI B1.2 GO UNC 1.5/8 x 5 2B Unified bước thô UNC
16734 €238.79 ANSI B1.2 GO UNC 1.3/4 x 5 2B Unified bước thô UNC
16735 €274.02 ANSI B1.2 GO UNC 1.7/8 x 4.5 2B Unified bước thô UNC
16736 €304.58 ANSI B1.2 GO UNC 2" x 4.5 2B Unified bước thô UNC
16737 €342.86 ANSI B1.2 GO UNC 2.1/4 x 4.5 2B Unified bước thô UNC
16738 €391.85 ANSI B1.2 GO UNC 2.1/2 x 4 2B Unified bước thô UNC
16739 €433.22 ANSI B1.2 GO UNC 2.3/4 x 4 2B Unified bước thô UNC
16740 €433.22 ANSI B1.2 GO UNC 3" x 4 2B Unified bước thô UNC
