Home Thread plug gauge VÖLKEL GO-NOGO thread plug gauge, UNC No. 2 – 1.1/2, tolerance 2B
Categories
VÖLKEL GO-NOGO thread plug gauge, UNC No. 2 – 1.1/2, tolerance 2B
Thread plug gauge

VÖLKEL GO-NOGO thread plug gauge, UNC No. 2 – 1.1/2, tolerance 2B

★ 0.0 (0 reviews)
Sold: 0
Views: 0
Imported from: Germany
Origin: Made in Germany

VÖLKEL GO-NOGO thread plug gauge, UNC No. 2 – 1.1/2, 22 sizes, to ANSI B1.2. Double-ended GO and NOGO gauge. For internal threads after tapping or repair.

SKU: 161xx
22 variants
€86.53 - €290.89
Stock status: Varies by SKU
Indicative price
Description

VÖLKEL GO-NOGO thread plug gauge, UNC No. 2 – 1.1/2, 22 sizes, to ANSI B1.2. Double-ended GO and NOGO gauge. For internal threads after tapping or repair.

Specifications

  • Function: inspection gauge for internal threads
  • Double-ended design: GO and NOGO on one body
  • GO end verifies minimum material condition
  • NOGO end verifies maximum material condition
  • Unified Coarse (UNC) inch thread system
  • Right-hand thread
  • Tolerance class: 2B
  • Manufactured to ANSI B1.2
  • Pass/fail result independent of operator
  • Application: thread check after tapping or thread repair
  • Use areas: production, maintenance, tool room, incoming inspection
  • Not for cutting, reforming or cleaning threads
  • Not suitable for external threads; use ring gauges
  • Insert by hand without force; stop if resistance occurs
  • Thread hole must be free of chips and burrs
  • Supply: one gauge per item
Price list & Ordering
Drag to reorder
SKU Code Price (EUR) Buy Stock DIN or ISO standard Probe type Thread size Thread tolerance class Thread type
16568 €96.46 ANSI B1.2 GO NOGO double-ended UNC No. 2 x 56 2B Unified bước thô UNC
16569 €96.46 ANSI B1.2 GO NOGO double-ended UNC No. 3 x 48 2B Unified bước thô UNC
16104 €91.83 ANSI B1.2 GO NOGO double-ended UNC No. 4 x 40 2B Unified bước thô UNC
16570 €96.46 ANSI B1.2 GO NOGO double-ended UNC No. 5 x 40 2B Unified bước thô UNC
16105 €91.83 ANSI B1.2 GO NOGO double-ended UNC No. 6 x 32 2B Unified bước thô UNC
16106 €91.83 ANSI B1.2 GO NOGO double-ended UNC No. 8 x 32 2B Unified bước thô UNC
16107 €93.34 ANSI B1.2 GO NOGO double-ended UNC No. 10 x 24 2B Unified bước thô UNC
16571 €91.83 ANSI B1.2 GO NOGO double-ended UNC No. 12 x 24 2B Unified bước thô UNC
16108 €86.53 ANSI B1.2 GO NOGO double-ended UNC 1/4 x 20 2B Unified bước thô UNC
16109 €89.41 ANSI B1.2 GO NOGO double-ended UNC 5/16 x 18 2B Unified bước thô UNC
16110 €89.41 ANSI B1.2 GO NOGO double-ended UNC 3/8 x 16 2B Unified bước thô UNC
16111 €102.63 ANSI B1.2 GO NOGO double-ended UNC 7/16 x 14 2B Unified bước thô UNC
16112 €97.90 ANSI B1.2 GO NOGO double-ended UNC 1/2 x 13 2B Unified bước thô UNC
16113 €130.08 ANSI B1.2 GO NOGO double-ended UNC 9/16 x 12 2B Unified bước thô UNC
16114 €139.31 ANSI B1.2 GO NOGO double-ended UNC 5/8 x 11 2B Unified bước thô UNC
16115 €156.12 ANSI B1.2 GO NOGO double-ended UNC 3/4 x 10 2B Unified bước thô UNC
16572 €165.38 ANSI B1.2 GO NOGO double-ended UNC 7/8 x 9 2B Unified bước thô UNC
16573 €174.50 ANSI B1.2 GO NOGO double-ended UNC 1" x 8 2B Unified bước thô UNC
16574 €221.91 ANSI B1.2 GO NOGO double-ended UNC 1.1/8 x 7 2B Unified bước thô UNC
16575 €238.79 ANSI B1.2 GO NOGO double-ended UNC 1.1/4 x 7 2B Unified bước thô UNC
16576 €270.16 ANSI B1.2 GO NOGO double-ended UNC 1.3/8 x 6 2B Unified bước thô UNC
16577 €290.89 ANSI B1.2 GO NOGO double-ended UNC 1.1/2 x 6 2B Unified bước thô UNC
