Home Thread plug gauge VÖLKEL GO-NOGO thread plug gauge, G BSP pipe 1/8 – 1.1/8
Categories
VÖLKEL GO-NOGO thread plug gauge, G BSP pipe 1/8 – 1.1/8
Thread plug gauge

VÖLKEL GO-NOGO thread plug gauge, G BSP pipe 1/8 – 1.1/8

★ 0.0 (0 reviews)
Sold: 7
Views: 0
Imported from: Germany
Origin: Made in Germany

VÖLKEL GO-NOGO thread plug gauge, G (BSP) pipe 1/8 – 1.1/8, 9 sizes, to DIN EN ISO 228-2. Double-ended GO and NOGO gauge. For internal threads after tapping or repair.

SKU: 1613x
9 variants
€82.70 - €198.99
Stock status: Varies by SKU
Indicative price
Description

VÖLKEL GO-NOGO thread plug gauge, G (BSP) pipe 1/8 – 1.1/8, 9 sizes, to DIN EN ISO 228-2. Double-ended GO and NOGO gauge. For internal threads after tapping or repair.

Specifications

  • Function: inspection gauge for internal pipe threads
  • Double-ended design: GO end and NOGO end on one body
  • GO end verifies thread engages freely
  • NOGO end verifies thread is not oversize
  • Thread form: cylindrical parallel pipe thread, right-hand
  • Pass/fail result in a single check operation
  • Application: thread holes after tapping, cleaning or repair
  • Use areas: production, maintenance, tool room, incoming inspection
  • Not intended for cutting, reworking or cleaning threads
  • Supplied as one piece per size
  • Check sequence: clean hole, screw in by hand, no force
Price list & Ordering
Drag to reorder
SKU Code Price (EUR) Buy Stock DIN or ISO standard Probe type Thread size Thread type
16128 €82.70 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 1/8 x 28 Ống trụ G BSP
16129 €88.78 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 1/4 x 19 Ống trụ G BSP
16130 €91.83 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 3/8 x 19 Ống trụ G BSP
16131 €96.46 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 1/2 x 14 Ống trụ G BSP
16132 €96.46 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 5/8 x 14 Ống trụ G BSP
16133 €116.32 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 3/4 x 14 Ống trụ G BSP
16134 €116.32 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 7/8 x 14 Ống trụ G BSP
16135 €136.25 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 1" x 11 Ống trụ G BSP
16589 €198.99 DIN EN ISO 228-2 GO NOGO double-ended G (BSP) 1.1/8 x 11 Ống trụ G BSP
