Sanitary Set - G 1/4 - 3/4" - Taps + Bàn ren lục giác

Application:

• Recutting and cleaning damaged BSP (G) threads
• Ideal for typical sanitary installations
• Suitable for maintenance, repair and assembly work
• Bàn ren lục giác according to DIN 382 made of HSS
• Short machine taps according to DIN 5157, Form D, HSS-G

Advantages:

• Practical set with the most common sanitary thread sizes
• No special holding tools required
• Clean and precise thread results
• Includes Gel cắt gọt ren for improved cutting performance
• Compact and functional storage

1. Identify the thread:
   Determine the BSP thread size (e.g. G 1/2 × 14) and select the matching tap or Bàn ren lục giác from the set.
2. Prepare the workpiece:
   Clean the existing thread and surrounding area from dirt, corrosion or residues to ensure proper alignment.
3. Apply Gel cắt gọt ren:
   Apply the included Gel cắt gọt ren to the tool and the thread to reduce friction and improve cutting quality.
4. Recut or clean the thread:
   Carefully guide the tap or die nut straight into the thread and turn evenly using suitable hand tools.
5. Remove the tool:
   Unscrew the tool completely after reaching the required depth and clean the thread from residues.
6. Final inspection:
   Check the thread using a suitable fitting. The thread should run smoothly and seat correctly.

• Thread type: G (BSP)
• Thread range: G 1/4 – G 3/4
• Material: HSS / HSS-G
• Die nuts: DIN 382
• Taps: DIN 5157, Form D
• Application: Hand use
• Article number: 48650
• EAN: 4022835486503

• Bàn ren lục giác DIN 382 HSS G (BSP) 1/4 × 19 (25514)
• Bàn ren lục giác DIN 382 HSS G (BSP) 3/8 × 19 (25516)
• Bàn ren lục giác DIN 382 HSS G (BSP) 1/2 × 14 (25518)
• Bàn ren lục giác DIN 382 HSS G (BSP) 3/4 × 14 (25522)
• Mũi taro máy ngắn DIN 5157 Form D HSS-G G (BSP) 1/4 × 19 (65314)
• Mũi taro máy ngắn DIN 5157 Form D HSS-G G (BSP) 3/8 × 19 (65316)
• Mũi taro máy ngắn DIN 5157 Form D HSS-G G (BSP) 1/2 × 14 (65318)
• Mũi taro máy ngắn DIN 5157 Form D HSS-G G (BSP) 3/4 × 14 (65322)
• Gel cắt gọt ren V4S, 120 ml (10903)

Is the set suitable for BSP threads only?
Yes, the set is specifically designed for G (BSP) threads. It is optimised for the most common sanitary thread sizes.

Can the tools be used in confined spaces?
Yes, the short taps and Bàn ren lục giác allow controlled work even in limited installation spaces.

Do I need special holders?
No, the tools can be operated with standard hand tools such as spanners or tap wrenches.

Does the Gel cắt gọt ren have to be used?
Using Gel cắt gọt ren is recommended to improve cutting quality and reduce tool wear, especially in thép fittings.

Are replacement tools available?
Yes, all taps, die nuts and accessories included in the set can be ordered individually.
