Application:
for general use
| Type of thread | metric ISO-thread |
|---|---|
| Standard | DIN 352 |
| Material | HSS-G |
| Tolerance | ISO2 (6H) |
| Size | M 16 x 2.0 LH |
| Overall length (L1) | 80 mm |
| Thread length (L2) | 32 mm |
| Core hole diameter (D1) | 14.0 mm |
| Shank diameter (D2) | 12.0 mm |
| Drive connector | 9.0 mm |
| Item number | 27058-3 |
| Type of flute | straight fluted |
| Application | for through and blind holes |
| Thread standard | DIN 13 |
