Application:
for general use
| Type of thread | metric ISO-thread |
|---|---|
| Standard | DIN 352 |
| Material | HSS-G |
| Tolerance | ISO2 (6H) |
| Size | M 10 x 1.5 LH |
| Overall length (L1) | 70 mm |
| Thread length (L2) | 24 mm |
| Core hole diameter (D1) | 8.5 mm |
| Shank diameter (D2) | 7.0 mm |
| Drive connector | 5.5 mm |
| Item number | 27046-3 |
| Type of flute | straight fluted |
| Application | for through and blind holes |
| Thread standard | DIN 13 |
