STI Fluteless Machine Tap ISO 529 Form C HSSE - M 4 x 0.7

Name: STI Fluteless Machine Tap ISO 529 Form C HSSE - M 4 x 0.7
Brand: VOLKEL
SKU: 03607
Price: 508800.0 VND
Availability: OutOfStock

★ 0.0 (0 reviews) • Sold 0

STI Fluteless Machine Tap ISO 529 Form C HSSE - M 4 x 0.7 by VÖLKEL, item no. 03607, suitable for cutting internal threads.

SKU: 03607

508.800 đ

Stock status: Hết hàng

Price includes VAT

Description

STI Fluteless Machine Tap ISO 529 Form C HSSE - M 4 x 0.7

You use STI Fluteless Machine Tap ISO 529 Form C HSSE - M 4 x 0.7 for practical threading work where the existing thread standard, hole condition and drive concept have to be matched before the operation starts. It fits professional shop use where repeatability and correct assignment matter more than generic one tool solutions.

M denotes the ISO metric thread system used widely in mechanical engineering, maintenance and general fastener work where metric screw threads are standard. The HSSE material group is typically selected when you want higher hot hardness and wear resistance than standard HSS. STI denotes a thread form for wire thread inserts, so you select it when the goal is not a standard direct receiving thread but an insert ready repair thread. A fluteless tap forms the thread by displacement rather than chip removing cutting, so material ductility and lubrication are practical selection checkpoints.

Application

Producing insert receiving threads by forming instead of chip removing cutting in ductile materials
Selecting the process when surface finish and fiber continuity of the parent material are relevant checkpoints
Using sufficient lubrication and stable alignment for a controlled thread forming process
Process: manual driving or assisted driving depending on your holder and machine setup
Use: thread cutting, re tapping, and thread cleaning depending on condition

Note Select the product by thread designation, workpiece condition and the holder concept used in your process.

Benefits

Chip free thread forming supports clean holes and stable thread profile generation in ductile materials
Suitable for workshop, maintenance and machine room workflows with repeatable tool use
The explicit standard and material markings support controlled tool assignment in professional use
A dedicated threading tool reduces compromise compared with improvised general purpose tooling

Drawbacks

Tool selection still depends on matching the thread system, material and process type to the actual job.
It is intended for defined threading work and not for undirected high speed use without the correct setup and lubrication strategy.

Step by step

Prepare the hole for the insert receiving thread and apply suitable lubrication.
Clamp the fluteless STI tap securely in the selected holder or machine drive.
Start the tool square to the bore and maintain stable feed as the thread is formed.
Continue the forming process with controlled torque and without interrupting alignment.
Reverse the tool carefully after the receiving thread is completed.
Clean the formed thread and verify readiness for insert installation.

Scope of supply

1 piece STI Fluteless Machine Tap ISO 529 Form C HSSE - M 4 x 0.7

Technical features

Product type: STI fluteless tap
Thread system: Metric ISO
Standard: ISO 529
Form: Form C
Tool material or finish: HSSE

Frequently asked questions (FAQ)

What do you use STI Fluteless Machine Tap ISO 529 Form C HSSE - M 4 x 0.7 for?

You use this product for a defined threading step such as internal thread cutting, external thread cutting, hole preparation or controlled tool handling depending on the product type.

Where can you find more technical background?

For additional technical background, see Technical information machine taps as PDF.

What should you confirm before use?

Confirm the thread designation, the material behavior and the way the product is mounted or driven in your process.

Where can you find one more related technical reference?

For a second related reference, see Technical information fluteless machine taps as PDF.

What does the Metric ISO designation mean?

M denotes the ISO metric thread system used widely in mechanical engineering, maintenance and general fastener work where metric screw threads are standard.

Where can you find the catalog entry for this product group?

For catalog level orientation, see VD 23 catalog as PDF.

When do you choose a fluteless tap?

You choose a fluteless tap when the material is ductile enough for forming and when a chip free process is preferred for the hole condition.

How do you protect tool life in daily use?

Use stable alignment, suitable lubrication and a holder concept that matches the torque and guidance demands of the product.

Do you need help selecting or using the product?
Use the contact form.

Specifications

Type of thread	metric ISO-thread
Standard	ISO 529
Form	Form C
Material	HSSE
Tolerance	ISO1 (4H)
Size	M 4 x 0.7
Overall length (L1)	58 mm
Thread length (L2)	16 mm
Core hole diameter (D1)	4.2 mm
Shank diameter (D2)	5.0 mm
Diameter (B)	4.9 mm
Drive connector	4.0 mm
EAN	4022835036074
Item number	03607
Application	for through and blind holes
Thread standard	DIN 13

Optional Accessories

SKU	Price VNĐ	Product name & short description
05207	6.400	V-COIL Wire thread insert Screw locking type SL M 4 x 0.7 - 1.0 D (100 pcs.) V-COIL Wire thread insert Screw locking type SL M 4 x 0.7 - 1.0 D (100 pcs.) by VÖLKEL, item no. 05207, suitable for thread repair and reinforcement.
05307	6.720	V-COIL Wire thread insert Screw locking type SL M 4 x 0.7 - 1.5 D (100 pcs.) V-COIL Wire thread insert Screw locking type SL M 4 x 0.7 - 1.5 D (100 pcs.) by VÖLKEL, item no. 05307, suitable for thread repair and reinforcement.
05407	7.040	V-COIL Wire thread insert Screw locking type SL M 4 x 0.7 - 2.0 D (100 pcs.) V-COIL Wire thread insert Screw locking type SL M 4 x 0.7 - 2.0 D (100 pcs.) by VÖLKEL, item no. 05407, suitable for thread repair and reinforcement.
07207	4.800	V-COIL Wire thread insert Free running type S M 4 x 0.7 - 1.0 D (100 pcs.) V-COIL Wire thread insert Free running type S M 4 x 0.7 - 1.0 D (100 pcs.) by VÖLKEL, item no. 07207, suitable for thread repair and reinforcement.
07307	5.440	V-COIL Wire thread insert Free running type S M 4 x 0.7 - 1.5 D (100 pcs.) V-COIL Wire thread insert Free running type S M 4 x 0.7 - 1.5 D (100 pcs.) by VÖLKEL, item no. 07307, suitable for thread repair and reinforcement.
07407	5.760	V-COIL Wire thread insert Free running type S M 4 x 0.7 - 2.0 D (100 pcs.) V-COIL Wire thread insert Free running type S M 4 x 0.7 - 2.0 D (100 pcs.) by VÖLKEL, item no. 07407, suitable for thread repair and reinforcement.
07507	6.720	V-COIL Wire thread insert Free running type S M 4 x 0.7 - 2.5 D (100 pcs.) V-COIL Wire thread insert Free running type S M 4 x 0.7 - 2.5 D (100 pcs.) by VÖLKEL, item no. 07507, suitable for thread repair and reinforcement.
07607	7.360	V-COIL Wire thread insert Free running type S M 4 x 0.7 - 3.0 D (100 pcs.) V-COIL Wire thread insert Free running type S M 4 x 0.7 - 3.0 D (100 pcs.) by VÖLKEL, item no. 07607, suitable for thread repair and reinforcement.
