Thread Repair Kits M 48 x 4.0 - 1.5D

• Repair of worn or damaged threads
• Reinforcement of materials with low shear strength
• Recovery of rejected or scrapped parts
• Creation of new, strong, and durable threads
• Ideal for maintenance, installation, and small series work
• Stainless steel inserts according to DIN 8140, Type S, ISO 2 (6H), free running

Advantages:

• Improved load-bearing capacity after repair
• Resistant to temperature and corrosion
• High availability of standard and special sizes
• Simple manual use – no machine required
• Delivered in a robust and functional metal case

1. Preparation: Drill out the damaged thread to the STI core diameter, slightly countersink, and clean.
2. Tapping: Cut a new thread with the STI hand tap M48 × 4.0 using cutting oil.
3. Insertion: Screw in the V-COIL insert using the inserting tool until flush with the surface.
4. Tang removal: Break off the driving tang using the provided tool.
5. Inspection: Check the new thread with a screw or gauge.

• Brand: V-COIL
• Nominal size: M 48 × 4.0
• Repair length: 1.5D
• Thread inserts: DIN 8140 / Type S / free running / stainless steel / ISO 2 (6H)
• Packaging: Metal case
• Article number: 04243

• 1× STI Hand Tap ISO 529 HSS-G – M 48 × 4.0 (03076)
• 1× V-COIL Inserting Tool (Drive connector 3/4") – M 48 × 4.0 (08100)
• 10× V-COIL Wire Thread Inserts Free Running Type S – M 48 × 4.0 – 1.5 D (07384)

Is this suitable for aluminum or soft alloys?
Yes, the stainless steel inserts provide durable threads even in soft materials.

What does 1.5D mean?
The insert length is 1.5 times the nominal thread diameter, offering superior strength.

Can it be used manually?
Yes, the kit is designed for convenient hand use.

Are the inserts corrosion-resistant?
Yes, they are made from high-quality stainless steel resistant to heat and corrosion.

Can spare inserts be ordered separately?
Yes, all V-COIL inserts are available individually in different sizes and lengths.
