Precision Dưỡng kiểm ren trong (Tol. 6H) - M 16 x 1.0

Name: Precision Dưỡng kiểm ren trong (Tol. 6H) - M 16 x 1.0
Brand: VOLKEL
SKU: 16062
Price: 2238000.0 VND
Availability: OutOfStock

★ 0.0 (0 đánh giá)

Đã bán: 0

Nhập khẩu từ: Đức

Xuất xứ: Đức

Precision Dưỡng kiểm ren trong (Tol. 6H) - M 16 x 1.0 VÖLKEL, mã 16062, phù hợp cho kiểm tra độ chính xác của ren.

SKU: 16062

2.238.000 đ

Giá đã bao gồm VAT

Vui lòng liên hệ để được báo giá và tình trạng hàng.

Mô tả

Precision Dưỡng kiểm ren trong (Tol. 6H) - M 16 x 1.0

This thread gauge lets you check internal or ren ngoài directly at the machine or in incoming inspection, using a simple go no go decision.

Use a clean, lightly oiled gauge and a consistent feel, because contamination can create false rejects. M denotes ISO metric thread designation used for common metric screw threads in machine building and maintenance.

Ứng dụng

Inspect threads by limit gauging, with a clear go and no go decision.
Use in production checks, incoming inspection, and maintenance verification.
Suitable when you need fast pass fail confirmation without measurement equipment.
Process: manual driving or assisted driving depending on your holder and machine setup
Use: cắt ren, taro lại ren, and làm sạch ren depending on condition
Clean chips from the tool and hole regularly to reduce torque peaks and edge chipping.

Lưu ý Do not force the no go side, because the limit is intended to stop early by design.

Lợi ích

Fast pass fail assessment without measurement interpretation
Suitable for routine checks close to the production process
Supports consistent inspection when many operators are involved
Helps detect tool wear and process drift through repeated checks
Suitable for routine use in metal fabrication and plant engineering service

Hạn chế

Limited by work material hardness and by the stability of your clamping setup
Not intended for high performance production cycles without validated process parameters

Các bước thực hiện

Clean the thread and remove burrs, chips, and heavy Chất bôi trơn cắt gọt ren.
Identify the go and no go sides on the gauge body.
Apply a light protective film and align the gauge to the thread axis.
Turn the go side with a consistent, low effort feel until it seats or reaches the specified engagement length.
Apply the no go side with the same straight alignment and stop at the first resistance without forcing.
Record the result according to your inspection plan and protect the gauge after use.

Phạm vi cung cấp

1 chiếc Precision Dưỡng kiểm ren trong (Tol. 6H) - M 16 x 1.0

Đặc tính kỹ thuật

Product type: Dưỡng kiểm ren trong
Inspection principle: Limit gauging with go and no go acceptance
Thread designation: M

Câu hỏi thường gặp (FAQ)

How do you select the correct thread designation for this product Match the thread designation in the product name to the mating fastener or component standard, then confirm that your workpiece material and process setup suit the tool type. If you work with mixed standards, separate your tooling by thread family to avoid mix ups. How do you use the gauge without forcing Align the gauge to the thread axis and turn with a consistent, low effort feel. The go side should pass under normal hand force. The no go side is intended to stop early, so stop at first resistance and do not force it. What does a go no go result tell you It tells you whether the thread is within the acceptable tolerance limits for assembly. It does not provide a measured size. Use it to screen parts quickly and to monitor process drift through repeated checks. How do you reduce the risk of misalignment Start the tool with the axis visually aligned, then guide it through the first turns with low torque. Use stable workholding and avoid side load. If a thread feels tight early, remove the tool, clean chips, and inspect the entry. How do you handle gauge wear Avoid dropping the gauge and keep it free of dirt. Use light protection against corrosion and store it in a protective case. If results become inconsistent, replace the gauge or recalibrate according to your quality system. Where can you find the full VÖLKEL catalog section for this product family VG 23 catalog as PDF

Do you need help selecting or using the product?
Use the biểu mẫu liên hệ.

Thuyết minh kỹ thuật

Loại ren	metric-fine ISO-thread
Tiêu chuẩn	ISO DIN 13
Tolerance	6H
Kích thước	M 16 x 1.0
Mã hàng	16062
Tiêu chuẩn dưỡng	DIN ISO 1502 / DIN 2240
Chuẩn ren	DIN 13
